The Madison

Overview

• 14’ wide x 39’ long overall dimensions (outside overhangs)
• 13’ wide x 30’ long building dimensions = 546 sq ft Including porch 390 sq ft living
• 1 loft area 13’ x 14’ – 182 sq ft
• 1 main floor bedroom
• 1 full bathroom
• 13’ x 8’ porch
• Sleeps up to 4 people
• RVIA Seal Built to ANSI A119.5 Standards
• Built on a Trailer/Chassis – heavy-duty steel with detachable hitch

Exterior Designs

• 28 gauge, premier rib, metal siding (color TBD)
• 28 gauge, premier rib metal roof (color TBD)
• 2”x 6” roof rafters, 24” on-center w/ 1/2” OSB underlayment & ice guard
• 2”x 4” studs, 16” on-center w/ 7/16” OSB sheathing, house wrap & window/seam tape
• 2”x 6” floor joists, 16” on-center w/ ¾” OSB subfloor
• Anderson 100 series, double pane single hung windows (Black)
• Provia 36” full glass entry door (black)
• Matte black door hardware w/ deadbolt

Porch

• Treated wood porch posts and beams (unfinished)
• Treated wood railing (unfinished)
• Treated wood decking floor (unfinished)
• Pine on ceiling (clear finish)

Insulation

• R19 closed cell spray foam insulation in the floor, walls & ceiling

Interior Designs

• Luxury vinyl plank floor throughout (color TBD)
• Walls & ceilings ½” birch plywood (painted white)
• Poplar trim package with 2 panel interior doors (painted white)
• Matte black door hardware

Kitchen Designs

• Custom painted base & top cabinets with shaker style doors (color TBD)
• Soft close door hinges & drawer slides
• Single bowl sink (color TBD)
• Laminated countertops (color TBD)
• Faucet & cabinet hardware (matte black)
• 24” 4 burner oven (color black)
• 18” Dishwasher
• Mid size fridge (color black)
• Above the oven built in microwave (color black)

Bathroom Designs

• One piece 4’ x 3’ fiberglass shower (white)
• Custom painted vanity with shaker style door fronts (color TBD)
• Cultured marble top & single bowl sink (color TBD)
• Faucets & cabinet hardware matte black
• Standard elongated toilet (white)
• Exhaust vent fan with light combo
• Vanity mirror
• Vanity light
• Towel bars, toilet paper holder (matte black)

Utilities

• Hot water tank/heater 19 gallon electric
• Standard per code Interior outlets, switches, and GFCI receptacle (white covers)
• 2 Ceiling Fans w/ Lights (Black)
• Recessed lights throughout
• Exterior outlet w/ cover one by each entry door
• Exterior wall light one by each entry door (black)
• Frost resistant exterior faucet one on back of house
• Bosch ductless Mini Split – 1 – outside unit, 2 – inside units
• Safety features per code, fire extinguisher, smoke alarms & carbon monoxide detector
• 100 AMP breaker box w/ conduit for direct tie-In
• All plumbing drain lines ready to tie into 3” pipe
• Pex water lines ready to connect to main water supply
• Stacked laundry center – washer/dryer (white)

• Corrugated metal exterior siding ¼” ridges (color TBD) + $1,550
• Corrugated metal exterior roof ¼” ridges (color TBD) + $1,200
• Skirting material only – corrugated metal (color TBD) + $1,850
• Premier legacy rib textured exterior roof + $500
• Vinyl board & batten exterior siding 8” wide (color TBD) + $2,100
• Log exterior half round siding (stained color TBD) + $5,700
• Porch with composite decking (color TBD) + $2,500
• Aluminum porch railing (black) + $2,100
• Exterior steps treated wood + $1,300
• Pine T&G interior ceiling (dark stain finish) + $2,900
• Pine T&G interior walls (clear finish) + $6,400
• Pine T&G interior ceiling (clear finish) + $2,400
• Pine interior trim with 2 panel solid core doors (clear finish) + $525
• Poplar nickel gap interior walls (painted) + $13,900
• Quartz kitchen countertops (color TBD) + $1,900
• Butcher block kitchen countertops stained (color TBD) + $300
• Butcher block bathroom countertops stained (color TBD) + $225
• Tile backsplash kitchen (subway tile white) $2,550
• Queen bedframe with hydraulic lift for storage (painted color TBD) + $2,250
• Queen bedframe with drawers for storage (painted color TBD) + $4,300
• Custom bedroom headboard built-in 84” tall (painted color TBD) + $6,000
• Custom wardrobe bedroom built-in 24” x 60” (painted color TBD) + $3,100
• Custom painted 20” wide linen closet (In the Navy) + $2,850
• Custom 3’ x 4’ tile shower w/ glass door (tile color TBD) + $5,800
• Incinerating toilet + $6,200
• Composting toilet + $4,000
• On-demand gas tankless water heater + $1,250
• Pine Board & Batten Siding (Available on request)
• Fireplace electric or gas (Available on request)
• Tankless hot water heater (Available on request)
• In floor radiant hot water heat (Available on request)
• Ethernet wiring (Available on request)
• Additional recessed lights (Available on request)
• Internal blinds in the entry doors (Available on request)
• Custom window blinds (Available on request)
